Details:
Compliance standards:
ASTM D3776, ISO 3801, ISO 7211, BS 2471, BS 3424, BSEN 1049, IS 14716, IS 12673
Applications:
Used for sample cutting in various industries such as acrylic sheets, aluminum and foils, bags and luggage of cotton, Pulp, Paper, Printing, Packaging and leather, belts, foot ware, paper industry.
Details:
- The equipment consists of Sample cutter with safety catch lock and Long life cutting pads.
- High quality aluminum die casted main body
- Light weight and resilient
- Easy movement of top handle
- The Sample Cutter has 4 Nos. of German reversible blades.
- The blades are reversible in design i.e. If one side gets blunt due to continuous usage, the blades can be turned to the other side. In this way, all the four sides of the blades can be used.
- Each blade has numbered sides from 1-4 for convenience in changing the blades.
Features
The unit is recommended for yield testing i.e. the determination of weight per unit area. The sample cutter cuts out rapidly and accurately circular specimen of 100 Cm2, which is exactly 1 / 100th of a square meter with the depth of up to 5 mm. The result is grams, multiplied by 100, gives the GSM (Grams per square meter) directly.
